Wind
Turbine Whisper
|
|
Electric power from a Whisper wind generator can
easily provide the normal requirements of a sailboat, cabin, rural home,
small farm or business without power lines. Solar panels complement the
wind by providing electricity during the calm between weather fronts and
during seasonal low wind months. Each system includes an EZ-Wire system
center, a wiring center, load center, monitor and control device.
The EZ-Wire system center is a universal overcharging controller. The EZ-Wire
features a bright LED display to monitor batteries, wind output, solar
output, and DC load; circuit breaker; stop switch and a diversion load
option. Controller (included): 200 amp EZ-Wire
Warranty: 2 year full parts replacement
How
does it works ?
|
 |
Model |
H40 |
| Rotor
Diameter |
2,1m |
| Weight |
21kg |
| Start
up wind speed |
3,4m/s |
| Rated
output |
900W
at 12,5m/s |
| Voltage |
12/24V
36/48 V |
| |
|
| |
|
| |
|
| Tip |
LPE00304 |
12V |
H40,
includes EZ wind/pv controller 12V |
| Tip |
LPE00305 |
24V |
H40,
includes EZ wind/pv controller 24V |
| Tip |
LPE00306 |
36V |
H40,
includes EZ wind/pv controller 36V |
| Tip |
LPE00307 |
48V |
H40,
includes EZ wind/pv controller 48V |
|
|
 |
Model |
H80 |
| Rotor Diameter |
3m |
| Weight |
30kg |
| Start up wind speed |
3,1m/s |
| Rated output |
1000W
at 10,5m/s |
| Voltage |
12/24/
36/48 V |
| |
|
| |
|
| |
|
| Tip |
LPE00308 |
12V |
H80,
includes EZ wire wind/pv controller 12V |
| Tip |
LPE00309 |
24V |
H80,
includes EZ wire wind/pv controller 24V |
| Tip |
LPE00310 |
36V |
H80,
includes EZ wire wind/pv controller 36V |
| Tip |
LPE00311 |
48V |
H80,
includes EZ wire wind/pv controller 48V |
|
| |
Model |
H80 |
| Rotor
Diameter |
3m |
| Weight |
30kg |
| Start
up wind speed |
3,1m/s |
| Rated
output |
1000W
at 10,5m/s |
| Voltage |
12/24/
36/48 V |
| |
|
| |
|
| |
|
| Tip |
LPE00312 |
36V |
H80
Water Pumper, includes pump controller |
| Tip |
LPE00313 |
48V |
H80
HVT, 220V model includes EZ wind/pv controller +
transformer |
| Tip |
LPE00313 |
48V |
H80
Water Pumper, |
|
|
| |
Model |
H80 |
| Rotor Diameter |
3m |
| Weight |
30kg |
| Start up wind speed |
3,1m/s |
| Rated output |
1000W
at 10,5m/s |
| Voltage |
12
/ 24V 36/48 V |
| |
|
| |
|
| |
|
| Tip |
LPE00314 |
24V |
H80,
includes EZ Wire II wind controller 24V |
| Tip |
LPE00315 |
36V |
H80,
includes EZ Wire II wind controller 36V |
| Tip |
LPE00316 |
48V |
H80,
includes EZ Wire II wind controller 48V |
|
 |
Model |
H175 |
| Rotor
Diameter |
4,5m |
| Weight |
70kg |
| Start
up wind speed |
3,1m/s |
| Rated
output |
3200W
at 12m/s |
| Voltage |
12/24/
36/48 V |
| |
|
| |
|
| |
|
| Tip |
LPE00317 |
24V |
175,
includes EZ Wire II wind / pv controller 24V |
| Tip |
LPE00318 |
36V |
175,
includes EZ Wire II wind / pv controller 36V |
| Tip |
LPE00319 |
48V |
175,
includes EZ Wire II wind / pv controller 48V |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| |
|
|
|
|
|
|
